Welded mesh offers several advantages over traditional MS bar grids when used in flooring applications:

  • Strength & Stability: Welded mesh is created by welding steel wires at intersections, forming a rigid grid that provides excellent load-bearing capacity.
  • Ease of Installation: Unlike MS bar grids, which require manual tying and alignment, welded mesh comes pre-fabricated, reducing labor time and effort.
  • Durability: Welded mesh can be galvanized or PVC-coated, making it more resistant to corrosion and environmental wear compared to untreated MS bar grids.
  • Uniformity: The consistent spacing and welding of the mesh ensure uniform strength distribution, reducing weak points in flooring.
  • Cost Efficiency: Since welded mesh is pre-manufactured, it minimizes material wastage and speeds up construction, leading to cost savings.

Here are some key points from the technical data sheet on welded wire mesh panels:

  • Material Composition: The mesh is made of galvanized steel wire, which undergoes a hot-dip galvanizing process to enhance corrosion resistance.
  • Physical Properties:
    • Tensile Strength: 435-480 MPa
    • Elongation: 20-25%
    • Hardness: 150-170 HV1
  • Dimensions:
    • Wire diameters range from 2.5 mm to 3.4 mm.
    • Mesh sizes vary, with common configurations like 66x68mm, 100x100mm.
  • Coating: A thin zinc layer (0.020-0.030mm thick) is applied to prevent corrosion.
  • Applications: Used for flooring, construction, agriculture, fencing, gardening, and machine protection.
  • Storage Recommendations: Should be stored in dry, closed conditions below 50°C, protected from moisture and direct sunlight.

Here's a comparison between welded mesh and traditional MS bar grids based on specifications:

1. Material Composition

  • Welded Mesh: Made from galvanized steel, stainless steel, or mild steel with a protective coating.
  • MS Bar Grid: Made from mild steel bars, which may require additional coatings to prevent corrosion.

2. Strength & Durability

  • Quality Assurance: As a client-centric organization, they ensure stringent quality checks from raw material selection to final dispatch.
  • Expertise: With years of experience and a skilled team, they have become a reliable supplier in the Middle East, Europe, South Asia, and India.
  • Infrastructure: Located in Masjid Bunder, Mumbai, with modern manufacturing facilities.

3. Corrosion Resistance

  • Welded Mesh: Often galvanized or PVC-coated, offering better corrosion resistance.
  • MS Bar Grid: Susceptible to rust unless treated with paint or coatings.

4. Installation & Handling

  • Welded Mesh: Pre-fabricated panels, easy to install, reducing labor time.
  • MS Bar Grid: Requires manual tying and alignment, increasing labor costs.

5. Cost Efficiency

  • Welded Mesh: Lower material wastage, faster installation, reducing overall costs.
  • MS Bar Grid: Higher labor costs due to manual assembly.

6. Applications

  • Welded Mesh: Used in flooring, construction, fencing, agriculture, and machine protection.
  • MS Bar Grid: Primarily used in reinforced concrete structures
